| Mating Cycle: 500 Cycles | Voltage Rating: 300V+30V | Operating Temperature: -40°C to 105°C |
| Wire Processing: Solder | Current Rating: 20A+5A | IP Rating: IP67(Mated) |
| Insulation Resistance: 100MΩ at 500V DC | Withstand Voltage: 2,000V AC | Salt Spray: 5% NaCI, 48h |
Wire Gauge: Power 12AWG/ Max Signal 22AWG/ Max | Flammability Rating: UL94V-0 |
